Product Category: Loadcells

Low Range Donut Load Cell

Capacity / Rated Load: 7.5 – 50kN
Non – Linearity: 0.5%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

Medium Range Donut Load Cell - Low

Capacity / Rated Load: 10 – 200kN
Non – Linearity: 0.1%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

Medium- High Range Donut Load Cell

Capacity / Rated Load: 400 – 800kN
Non – Linearity: 0.25%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

High Range Donut Load Cell

Capacity / Rated Load: 1000 – 2000kN
Non – Linearity: 0.5%RL
Standard Variants: Cable or Connector Versions Available
Custom Options: High Temperature / Vacuum Compatible Versions Available

High Range Donut Load Cell - Low Profile

Capacity / Rated Load: 1000 – 4000kN
Non – Linearity: 1.0%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

Universal Load Washer

Capacity / Rated Load: 10 – 200kN
Non – Linearity: 0.5%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

Universal Load Washer - Low Profile

Capacity / Rated Load: 10 – 200kN
Non – Linearity: 2.0%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

Universal Cylindrical Load Cell - Female Threads

Capacity / Rated Load: 10 – 500kN
Non – Linearity: 0.2 – 0.5%RL
Standard Variants: Cable or Connector Versions Available
Custom Options: High Temperature / Vacuum Compatible Versions Available

Universal Cylindrical Load Cell - Female Threads

Capacity / Rated Load: 5- 1000kN
Non – Linearity: 0.05%RL
Special Features: Thread Sizes to Suit Standard Rod End Bearing / Rose Joints
Standard Variants: Cable or Connector Versions Available
Custom Options: High Temperature / Vacuum Compatible Versions Available

Universal Cylindrical Load Stud - Male Threads

Capacity / Rated Load: 15 – 60kN
Non – Linearity: 0.1%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

Compact Canister Load Cell with Load Ring

Capacity / Rated Load: 5 – 40kN
Non – Linearity: 0.5%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

Compact Canister Load Cell with Load Button

Capacity / Rated Load: 100 – 400kN
Non – Linearity: 0.5%RL
Standard Variants: Axial or Radial Cable Versions Available
Custom Options: High Temperature / Vacuum Compatible Versions Available

Universal Canister Load Cell with Load Button

Capacity / Rated Load: 10 – 2000kN
Non – Linearity: 0.05 – 0.4%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

Low Range Pancake Load Cell

Capacity / Rated Load: 1 – 10kN
Non – Linearity: 0.1%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

Medium Range Pancake Load Cell

Capacity / Rated Load: 25 – 200kN
Non – Linearity: 0.1%RL
Special Features: In Line Adaptor Plates, Fixing Kits and Other Load Fittings Available
Standard Variants: Cable or Connector Versions Available
Custom Options: High Temperature / Vacuum Compatible Versions Available

Universal Pancake Load Cell

Capacity / Rated Load: 1 – 500kN
Non – Linearity: 0.1%RL
Special Features: In Line Adaptor Plates, Fixing Kits and Other Load Fittings Available
Standard Variants: Cable or Connector Versions Available
Custom Options: High Temperature / Vacuum Compatible Versions Available

1/2" Diameter Miniature Diapraghm Load Cell

Capacity / Rated Load: 250N – 1kN
Non – Linearity: 0.5%RL
Standard Variants: Compression Only Load Button and Tension / Bi-directional M3 Male Thread Versions Available

15mm Diameter Miniature Diapraghm Load Cell

Capacity / Rated Load: 100 – 800N
Non – Linearity: 0.5%RL
Standard Variants: Compression Only Load Button and Tension / Bi-directional M4 Male Thread Versions Available

20mm Diameter Miniature Diapraghm Load Cell

Capacity / Rated Load: 100N – 3.2kN
Non – Linearity: 0.5%RL
Standard Variants: Compression Only Load Button and Tension / Bi-directional M5 Male Thread Versions Available

30mm Diameter Miniature Diapraghm Load Cell

Capacity / Rated Load: 100N – 6.4kN
Non – Linearity: 0.5%RL
Standard Variants: Compression Only Load Button and Tension / Bi-directional M6 Male Thread Versions Available

Deci-Newton Axial Bending Beam Load Cell

Capacity / Rated Load: 0.1N
Non – Linearity: 0.2%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

Ultra Low Range Axial Bending Beam Load Cell

Capacity / Rated Load: 10 – 500N
Non – Linearity: 0.15%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

Low Range Axial Bending Beam Load Cell - Female Drive

Capacity / Rated Load: 30 – 300N
Non – Linearity: 0.05%RL
Standard Variants: Compression Only Load Button Version Available

Low Range Axial Bending Beam Load Cell - Male Drive

Capacity / Rated Load: 100 – 800N
Non – Linearity: 0.1%RL

Compact Low-Medium Range Axial Load Cell

Capacity / Rated Load: 50N – 2.5kN
Non – Linearity: 0.1 – 0.35%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

Universal Bending Beam Load Cell

Capacity / Rated Load: 200N – 60kN
Non – Linearity: 0.05%RL
Special Features: High Level of Compensation for Off-Axis Forces
Standard Variants: Compression Only Flat or Convex Base and Tension / Bi-directional Thread or Eye Base Versions Available
Custom Options: High Temperature / Vacuum Compatible Versions Available

Universal Shear Beam Load Cell

Capacity / Rated Load: 80 – 240kN
Non – Linearity: 0.1%RL
Standard Variants: Compression Only Flat or Convex Base and Tension / Bi-directional Thread Base Versions Available
Custom Options: High Temperature / Vacuum Compatible Versions Available

Premium Universal Bending Beam Load Cell

Capacity / Rated Load: 1 – 400kN
Non – Linearity: 0.03%RL
Special Features: High Level of Compensation for Off-Axis Forces
Custom Options: High Temperature / Vacuum Compatible Versions Available

Low Range Single Point Bending Beam Load Cell

Capacity / Rated Load: 1 – 3N
Non – Linearity: 0.1%RL

Single Point Bending Beam Load Cell

Capacity / Rated Load: 50 – 300N
Non – Linearity: 0.05%RL

Single Point Shear Beam Load Cell

Capacity / Rated Load: 5 – 160kN
Non – Linearity: 0.1%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

Universal In-line Shear Force Load Cell

Capacity / Rated Load: 5 – 50kN
Non – Linearity: 0.05%RL
Special Features: Can be Used to Support a Large Cantilever Load
Custom Options: High Temperature / Vacuum Compatible Versions Available

Low Cost Diaphragm Load Cell with Load Button

Capacity / Rated Load: 20 -40kN
Non – Linearity: 2.0%RL
Special Features: Supplied Without a Full Calibration Certificate, Intended for Large Volume OEM Applications Only

Diaphragm Load Cell with Load Button

Capacity / Rated Load: 5 – 50kN
Non – Linearity: 0.5%RL
Special Features: Dual Fixing Options for Increased Versatility
Custom Options: High Temperature / Vacuum Compatible Versions Available

Diaphragm Load Cell with Load Button - Low Profile

Capacity / Rated Load: 50 – 100kN
Non – Linearity: 0.5%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

Diaphragm Load Cell with Load Ring - Low Profile

Capacity / Rated Load: 50N – 10kN
Non – Linearity: 0.3 – 0.5%RL
Custom Options: High Temperature / Vacuum Compatible Versions Available

3-Axis Gear Shift Load Cell

Capacity / Rated Load: 200N
Non – Linearity: 0.5%RL
Special Features: Ergonomic Design. Direct Replacement of Existing Part
Custom Options: Custom Force Ranges / Dimensions and Single or 2-Axis Versions Available

Custom Low Range 2-Axis Load Cell

Capacity / Rated Load: 0.1 – 100N
Non – Linearity: 0.5%RL
Special Features: Both Axes 90° to Each Other in Vertical Plane
Custom Options: Custom Force Ranges / Dimensions Available

Custom Medium - High Range 2-Axis Load Cell

Capacity / Rated Load: 2 – 10kN
Non – Linearity: 0.5%RL
Special Features: Both Axes 90° to Each Other in Vertical Plane
Standard Variants: Spherical Bearing or Hard Fixing Options Available
Custom Options: Custom Force Ranges / Dimensions Available

Custom Low - Medium Range 2 or 3-Axis Load Cell

Capacity / Rated Load: 100N – 5kN
Non – Linearity: 0.5%RL
Special Features: 2-Axis Version Configurable for 90° in Either Vertical or Horizontal Plane
Custom Options: Custom Force Ranges / Dimensions Available

Custom Medium - High Range 2 or 3-Axis Load Cell

Capacity / Rated Load: 10 – 20kN
Non – Linearity: 0.3%RL
Special Features: 2-Axis Version Configurable for 90° in Either Vertical or Horizontal Plane
Custom Options: Custom Force Ranges / Dimensions Available

Axial Force and Torque Load Cell

Capacity / Rated Load: Custom Range
Non – Linearity: 0.05%RL

Custom Static Torque Transducer - Low Profile

Capacity / Rated Load: Custom Range
Non – Linearity: 0.5%RL
Special Features: High Level of Compensation for Off-Axis Force. Excellent for Robotics Applications
Custom Options: Custom Force Ranges / Dimensions Available

Custom Shear Pin Load Cell

Capacity / Rated Load: Custom Range
Non – Linearity: 0.1 – 0.3%RL
Custom Options: Custom Force Ranges / Dimensions Available

Radial Web Tension / Roller Bearing Load Cell

Capacity / Rated Load: 50 – 500N
Non – Linearity: 0.03%RL

Low Range Axial Proving Ring Load Cell

Capacity / Rated Load: 0.5 – 20N
Non – Linearity: 0.2%RL

Low Range Axial Proving Ring Load Cell

Capacity / Rated Load: 0.5 – 20N
Non – Linearity: 0.2%RL
