This is greatly simplified by the free T24 Toolkit software for Windows supplied with the unit. Data can also be captured by the base station from a number of T24 data acquisition modules to provide a computer based wireless data logger. The number of data acquisition units that can be handled by a base station is dependant upon the data rate required.
T24 toolkit software is available for set-up and data access using a computer with a Windows operating system, Windows XP, Vista , 7, 8 or 10 is required. The software can output data as a standard csv file for use with a spreadsheet or other data processing software.
The licence free 2.4GHz direct sequence spread spectrum (DSSS) radio technology offers high integrity, error free communications which can co-exist with other wireless technologies such as Wi-Fi, Bluetooth® and Zigbee®.
CE – Complies with EMC directive, 2004/108/EC. The Radio Equipment and Telecommunications Terminal Equipment (R&TTE) Directive, 1999/5/EC. RoHS compliant.
This is greatly simplified by the free T24 Toolkit software for Windows supplied with the unit. Data can also be captured by the base station from a number of T24 data acquisition modules to provide a computer based wireless data logger. The number of data acquisition units that can be handled by a base station is dependant upon the data rate required.
T24 toolkit software is available for set-up and data access using a computer with a Windows operating system, Windows XP, Vista , 7, 8 or 10 is required. The software can output data as a standard csv file for use with a spreadsheet or other data processing software.
The licence free 2.4GHz direct sequence spread spectrum (DSSS) radio technology offers high integrity, error free communications which can co-exist with other wireless technologies such as Wi-Fi, Bluetooth® and Zigbee®.
CE – Complies with EMC directive, 2004/108/EC. The Radio Equipment and Telecommunications Terminal Equipment (R&TTE) Directive, 1999/5/EC. RoHS compliant.
Parameter | Value | Unit |
---|---|---|
USB power supply range | 4.875 (Min) / 5.0 (Typical) / 5.125 (Max) | V |
USB operating current | 100 (Min) / 200 (Max) | mA |
Licence | Licence exempt | |
Modulation method | MS (QPSK) | |
Radio type | Transceiver (2 way) | |
Data rate | 250 | kbits/sec |
Radio frequency | 2.4000 (Min) / 2.4835 (Max) | GHz |
Power | 10 | mW |
Line of sight transmission distance | 400 | m |
Channels (DSSS) | 16 | |
USB cable length | 1.3 | m |
Operating temperature range | -20 (Min) / 55 (Max) | °C |
Storage temperature | -40 (Min) / 85 (Max) | °C |
Humidity | 0 (Min) / 95 (Max) | %RH Non condensing |
Sealing | IP50 |
Code | Description |
---|---|
T24-BSu | Cased telemetry base unit with USB interface. |
T24 manual is available for download. The T24 system can be calibrated in a number of different ways depending upon the application. Please consult our engineering department for help with your requirements. | |
Please see Engineering Sheet E035 for Frequently Asked Questions for the T24 Telemetry system. |
